New APS Series

A new standard in packaged refrigeration condensing units.

Acpac is our exclusive packaged refrigeration condensing unit range. This successful new range, manufactured specially for Actrol by Tecumseh, includes models with hermetic, scroll, and semi-hermetic compressors.

Acpac is a fully optioned series which is kept in stock, allowing it to be used for both new projects and breakdown replacement projects.

The APS semi hermetic range has now been extended with the inclusion of more Tecumseh Semi Hermetic compressors for both medium and low temperature applications.

Eight models have been available since last summer, in refrigeration capacities from 4.6kW to 33.6kW at medium temperature and 0.99kW and 8.3kW at low temperature.

The APS range is fully fitted, wired, and protected, making it easy to apply to many cooling and freezing applications such as supermarkets, fast foods outlets, restaurants, food processors, butchers, florists, and many other applications.

We now have four new models arriving to extend the series significantly.

These four models range in capacity from 39.5kW to 64.2kW at medium temperature and 9.5kW to 16.5 kW at low temperature.

With this new range, Acpac APS now covers nearly every refrigeration application, making it the new standard in packaged refrigeration condensing units.

Factory fitted features include:

  • Tecumseh semi-hermetic compressor with temporary transport mounts
  • Suction accumulator
  • Demountable suction filter
  • Liquid line filter drier
  • Full wiring including contractors and electronic overloads
  • DOL and PWS compressor starting, model dependant
  • Pressure relief valve
  • Generous condenser/s with blue fin protection
  • EBM condenser fans with head pressure control
  • Fully galvanised and powder coated cabinets

New extension models also include:

  • EC condenser fans to provide infinite fan speed control and reduced energy usage
  • Ziehl Abegg fan speed control for quick and easy set up
  • PWS start compressor
  • Compressor electronic oil protection
  • Demountable shell liquid line filter drier

New Extension Models

2701982 ACPAC PACKAGED APS4.6ML2-1
2701983 ACPAC PACKAGED APS6.0ML2-1
2701984 ACPAC PACKAGED APS8.3ML2-1
2701985 ACPAC PACKAGED APS11.7ML3-1
2701986 ACPAC PACKAGED APS14.4ML3-1
2701987 ACPAC PACKAGED APS19.0ML2-1
2701988 ACPAC PACKAGED APS25.8ML2-1
2701989 ACPAC PACKAGED APS33.6ML2-1
2702251 ACPAC PACKAGED APS39.5ML2-1
2702252 ACPAC PACKAGED APS46.5ML2-1
2702253 ACPAC PACKAGED APS56.4ML2-1
2702254 ACPAC PACKAGED APS64.2ML2-1
